Wholesale Factory four strings 500V Pv Strings 4 in 1 Dc Combiner Box
MGV-DCPV4(NON INTELLIGENT WITHOUT ANTI REVERSE)
minimum order
10 pieces
Supply Ability
10pieces / Week
Country of Origin
Zhejiang,China
Stock Time
10Day
Quantity:
US $171.00 - US $178.00
/ pieces
Pv Combiner BoxPv Combiner BoxPv Combiner Box4 In 1 Out4 In 1 Out4 In 1 Out
| Model | MGV-DCPV4 |
|---|---|
| Sytem DC Voltage | 1000V |
| Each Input Current | 20A |
| Number of Input | 4 Strings |
| Max. Output Current | 80A |
| Number of Output | 1 |
| Lightning Protection | |
| Test Category | II |
| Nominal Discharge Current | 20kA |
| Max. Discharge Current | 40kA |
| Voltage Protection Level | 3.8kV |
| Max. Voltage | 1000V |
| Number of Poles | 3P |
| Structural Characteristics | Pluggable module |
| Protection Level | IP66 |
| Output Switch | DC circuit breaker (standard)/DC isolator switch (optional) |
| MC4 Connector | Optional |
| PV DC Fuse | Standard |
| PV DC SPD | Standard |
| Monitor Module | No |
| Diode | No |
| Heat Dissipation Plate | No |
| Shell Material | ABS |
| Installation Mothed | Wall-mounted |
| Working Temperature | -25°C '~+55°C |
| Altitude | 2000M |
| Permissible RH | 0-95%, no condensation |
